Bevel cutting
45° Bevel cutting. Suitable for cutting various pipe materials, including round pipes, square pipes, and rectangular pipes.
Industry-Leading Bed Manufacturing Technology
The machine tool adopts an open mechanical structure with a frame, and the crossbeam and bed body are processed as a whole. The equipment has high accuracy, good rigidity, and runs smoothly; At the same time, it has a compact structure, a small footprint, convenient operation and maintenance.
Full-Stroke Pneumatic Chuck
A single tube can bear a weight of 75kg, with a repeated positioning accuracy of 0.05mm and a maximum speed of 150r/min. The front chuck is a fixed installation method and cannot be moved.
Excellent Performance
Mampu memotong berbagai jenis pipa: pipa bulat, pipa persegi, pipa persegi panjang, baja kanal, baja siku, dan balok-I. Cocok untuk berbagai industri pengolahan pipa.
Parameter Teknis
Model | LX-T12 |
Kekuatan Laser | 2000~3000w |
Laser wavelength | 1070 nm |
Minimum line width | ≤0.15mm |
Cooling mode | water cooling |
Akselerasi | 1.2G |
Diameter Pemotongan Tabung Bulat | Φ20-120mm |
Memotong Diameter Tabung Persegi | ▢20*20-120*120mm |
X-axis | 6900mm |
B-axis | 360° (infinite rotation) |
Z-axis | 200mm |
Y-axis | 250mm |
Hole position accuracy | ±0.15mm |
Groove position accuracy | ±0.25mm |
Dimensi (P * L * T) | 9100*2600*2300mm |
Berat | ≈4.5T |
Jenis Tabung Pemotong | Tabung Bulat / Tabung Persegi |
Bahan Pemotongan | baja tahan karat, baja karbon, aluminium, tembaga, besi |
Tail length | Bevel cutting: >450mm Vertical cutting: >100mm |
