Bevel cutting
45° Bevel cutting. Suitable for cutting various pipe materials, including round pipes, square pipes, and rectangular pipes.
Industry-Leading Bed Manufacturing Technology
The machine tool adopts an open mechanical structure with a frame, and the crossbeam and bed body are processed as a whole. The equipment has high accuracy, good rigidity, and runs smoothly; At the same time, it has a compact structure, a small footprint, convenient operation and maintenance.
Full-Stroke Pneumatic Chuck
A single tube can bear a weight of 75kg, with a repeated positioning accuracy of 0.05mm and a maximum speed of 150r/min. The front chuck is a fixed installation method and cannot be moved.
Excellent Performance
Capable of cutting various types of pipes: round pipes, square pipes, rectangular pipes, channel steel, angle steel, and I-beams. Suitable for various pipe processing industries.
Technical Parameter
Model | LX-T9 |
Laser Power | 1500~3000w |
Laser wavelength | 1070 nm |
Minimum line width | ≤0.15mm |
Cooling mode | water cooling |
Acceleration | 1.5G |
Cutting Diameter Of Round Tube | Φ20-90mm |
Cutting Diameter Of Square Tube | ▢15*15-60*60mm |
X-axis | 100mm |
B-axis | 360° (infinite rotation) |
Z-axis | 80mm |
Y-axis | 800mm |
Hole position accuracy | ±0.15mm |
Groove position accuracy | ±0.25mm |
Dimensions (L*W*H) | 2450*1530*2000mm |
Weight | ≈1.2T |
Cutting Tube Type | Round Tube / Square Tube |
Cutting Material | stainless steel, carbon steel, aluminum,copper,iron |
Tail length | Bevel cutting: >260mm Vertical cutting: >160mm |
